About us

We specialize insuper-hardness machining for special non - standard new items with different size and tolerance. Possessed of cutting - edge & comprehensive production system , as well as rich producing & machining capability with different precision technology , so as to realize high efficiency application.

According to drawings or samples , we can customize CNC precision knife moulds , forming fixtures , brazing fixtures , wear - resistant parts , high - precision accessories by (3DX technology ) profile , super - hard , super - fine grinding with ceramics , tungsten steel , diamond , ultra - high anti - rust high - hardness high - toughness stainless steel , titanium alloy , titanium and other series.

Our products are able to process various materials whatever are micro - thin , super - long , super - thin , super - wear - resistant , impact - resistant , top complex , and combined profile , will all provided with perfect cutting quality and tolerance of dimension fine to ±0.0005mm(±0.5 u m ), and a high - efficiency & low - cost application we deliver to you!

Ultra micro - grain , long cutting age , perfect durability Can be made to order according to graph and sample.

Overview

Our Professional Broach Cutters are designed with precision to meet the high demands of modern manufacturing processes. Specializing in combined and solid rifling broaches over Φ10mm and various non-rifling broaches, we provide tailored solutions to enhance machining efficiency and product quality.

Material and Specifications

• VRA201:

  • Material: Imported ultra micro-grain diamond tungsten steel.

  • Properties: Offers excellent impact resistance and general wear resistance for machining materials of lower hardness (HRC≤25°). Ideal for discontinuous cutting and less stable fixtures.

  • Durability: Provides 4-6 times the lifespan compared to conventional materials like M42, ASP60, enhancing cost-effectiveness.

  • Standard: Conforms to ISO K25.

• ASP60A:

  • Material: Imported ultra high wear-resistant high-grade high cobalt powder steel, quenched to HRC70°±2°.

  • Properties: Exceptional wear and impact resistance, suitable for machining hard materials including high alloy, heat-resistant alloy, and stainless steel.

  • Applications: Often used in general equipment before heat treatment, supporting higher cutting speeds and effective machining of tough materials.

• MR11:

  • Material: Ultra micro-grain quality carbide.

  • Properties: Excellent wear resistance and ideal impact resistance for mid to high-speed intermediate cutting of materials with hardness between HRC 28° and 48°.

  • Performance: Offers 2-3 times the lifespan of general tungsten steel. After TiALN coating, it effectively machines materials up to HRC 60°.

• HRF10:

  • Material: Ultra micro-grain quality carbide.

  • Properties: High wear resistance suited for medium and low-speed cutting of high hardness materials (HRC45°-65°).

  • Standard: Corresponds to ISO K10, designed for stable cutting conditions and light machining.

Customization and Tailored Solutions

• Shape and Size Customization: We produce broaches in a variety of shapes and sizes based on customer drawings or samples, ensuring precise compliance with the required specifications.

• Surface Finish and Profile: We offer mirror surface finish grinding to provide high-quality finishes and accurate profiles, enhancing the functionality and durability of the broaches.

Key Features & Benefits

• High Precision and Efficiency: Designed to perform highly efficient machining with superior rigidity.

• Extended Tool Life: Advanced materials and manufacturing processes result in tools that last significantly longer than standard options.

• Customizable Features: Ability to customize inclinations, number of flutes, types of holders, and more, according to specific machining requirements.

Applications in Manufacturing

• Industrial Manufacturing: Suitable for creating precision components in industries such as automotive, aerospace, and heavy machinery.

• Specialty Applications: Ideal for tasks requiring special, non-standard shapes or new product designs.

Product Classification

• High-Performance Industrial Tools: Classified for use in high-demand industrial settings where precision and durability are paramount.

Note

Some products on this page may be custom designed according to specific customer requirements. The design copyright belongs to the original designer. If you are interested in customizing a similar product, please contact our sales team.
